Video wall & LED resolution calculator

Enter your screens or LED cabinets. You get the exact canvas to design at, including the pixels your bezels hide, a crop map for every screen and a design guide at full size.

An AV engineer measuring a six-panel video wall in a modern airport concourse.

See how it works · 7 steps

Pick your screens

Choose the model on your wall. castv.ai knows its pixels, its size and how thick its frame is.

Use it free in castv.ai

Have an account? Sign in and open it

Wall systemChoose the hardware you are measuring.
01
Screen & layoutChoose the panel, grid and mounting details.
Screens hang

Seam between two screens: 11 mm. Picture area 1,217 × 685 mm per screen, from the diagonal.

More optionsPanel pixels, when your screen isn't in the list

Design your content at

1920 × 1080px

16:9 Landscape, a standard shape

1 by 1 wall, design canvas 1,920 by 1,080 pixels, 1.23 m wide

Canvas

Design canvas
1920 × 1080px

16:9

Screens show, side by side
1920 × 1080px

16:9

Hidden behind bezels
0 × 0px

across · down

One screen
1920 × 1080px

Design one picture at the canvas size. It counts the pixels the frames hide, so a line drawn across the wall stays straight from screen to screen.

Physical

Physical size
1,229 × 696mm

4.0 ft × 2.3 ft

Diagonal
55.6″

0.85 m² of picture

Pixel pitch
0.634mm

centre to centre

Seam between two screens
11mm

How big the wall really is on the fixing, and how fine its pixels are — the numbers the installer and the room need.

Viewing

How far away people can stand: too close and the pixels show, too far and the detail is lost.

Closest comfortable
0.6 m 2.0 ft
1 m for every mm of pixel pitch, the LED industry rule
Whole picture in view
1.7 m 5.6 ft
The wall fills a 40° field of view
Pixels blend from
2.2 m 7.2 ft
Where one pixel is smaller than the eye can resolve (20/20 vision)
Small text readable to
5.6 m 18.4 ft
8 × picture height (AVIXA 4/6/8 rule)
Design guideA full-size guide to hand your designer

A guide at exactly 1920 × 1080 px: each screen numbered with its position, the strips the bezels hide hatched, the 5 % graphics-safe area dashed, and the centre marked. Put it on a layer above your artwork.

Design guide for the 1 × 1 wall
Crop mapWhere each screen's picture sits, to the pixel

Where each screen’s picture sits in the design canvas. Every screen gets exactly this tile, cut on the server.

1 result
11, 1001920 × 1080
1–1 of 1 result (1 total)
Photo: Pixabay · Pexels License. The window shows the real castv.ai tool, running on sample settings.

Where the answers come from

The bezel gaps come from the same formula castv.ai uses to cut each screen's tile on the server: both neighbours' bezels, converted at each screen's pixel pitch, averaged and rounded to an even number of pixels. Viewing distances use the LED industry's 1 m per mm of pitch, one arcminute of 20/20 vision, a 40° field of view and AVIXA's 4/6/8 rule.
